20.7Mpa Changeover Manifold High Flow Rate Pressure Regulator Device Easy To Control

Brand Name : AFK

Model Number : WL400

Place of Origin : China

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 pieces per week

Delivery Time : 5-7 days

Packaging Details : Export Packing

Price : Negotiable

Certification : CE

Material : Stainless Steel

Inlet pressure : 2200,3000 psi

Outlet Pressure : 25,50,100,150,250 psi

CV : 0.14

Contact Now

20.7Mpa High Flow Rate Pressure regulator device easy to control Flow Regulator

Quick Details

Material:stainless steel

Max.Inlet Pressure:3000 psig

Max.Outlet Pressure:250 psig

Working Temperature:-40℃~74℃

CV:0.14

Leakage Rate:2 *10-8 atm cc/sec He

Detail Image

Selection Table
WL4	2	1	5	H	S	1	N2
Series	Inlet connection	Outlet connection	Body	Inlet pressure	outlet pressure	Gauge	N2
WL4	1:6mm barb fitting	1: 1/4" welding	s: ss316	H:1000PSI	1:25PSI	1:Mpa	O2
	2:1/4"O.D.	2: 3/8"welding	C:nickel plated brass	M:500psi	2:50PSI	2:bar/PSI	H2
	3:8mm barb fitting	5.1/2" welding		L:300PSI	3:100PSI	3:PSI/kpa	C2H2
	4:3/8"O.D.	7: 1/4"O.D.			4:150PSI		CH4
	5:10mm barb fitting	8:3/8"O.D.			5:250PSI		AR
	6:1/2"O.D.	9: 1/2"O.D.					HE
							Air

Related Product

Specification:

Product Name:R11 pressure regulator
Maximum Inlet Pressure: 3000 Psi
Maximum Outlet Pressure: 500Psi
Safety Test Pressure:1.5 times of Maximum Rated Pressure
working Temperature: -40℃~74℃
CV 0.08

20.7Mpa Changeover Manifold High Flow Rate Pressure Regulator Device Easy To Control

Product Name	WL100 single side gas supply high pressure regulator device
Material	stainless steel
Max.Inlet Pressure	3000 psig
Max.Outlet Pressure	250 psig
Working Temperature	-40℃~74℃

20.7Mpa Changeover Manifold High Flow Rate Pressure Regulator Device Easy To Control

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
