Main Features of Gas pressure regulator
1) Single -stage reduce Structure.
2) Use hard-seal between body and diaphragm
3) Body Thread : 1/4" NPT ( F )
4) Easy to sweep inside body
5) Filter mesh inside
6) Panel mountable or wall mounted
Ordering Information
| R11 | L | B | B | D | G | 00 | 02 | P |
| Item | Body Material | Body Hole | Inlet Pressure | Outlet
Pressure | Pressure Guage | Inlet
size | Outlet
size | Mark |
| R11 | L:316 | A | D:3000 psi | F:0-500psig | G:Mpa guage | 00:1/4″NPT(F) | 00:1/4″NPT(F) | P:Panel mounting |
| | B:Brass | B | E:2200 psi | G:0-250psig | P:Psig/Bar Guage | 01:1/4″NPT(M) | 01:1/4″NPT(M) | R:With relief valve |
| | | D | F:500 psi | K:0-50pisg | W:No guage | 23:CGGA330 | 10:1/8″ OD | N:Needle calve |
| | | G | | L:0-25psig | | 24:CGGA350 | 11:1/4″ OD | D:Diaphregm valve |
| | | J | | | | 27:CGGA580 | 12:3/8″ OD | |
| | | M | | | | 28:CGGA660 | 15:6mm OD | |
| | | | | | | 30:CGGA590 | 16:8mm OD | |
| | | | | | | 52:G5/8″-RH(F) | | |
| | | | | | | 63:W21.8-14H(F) | | |
| | | | | | | 64:W21.8-14LH(F) | | |
Product Application of R41
R11 Series stainless steel pressure regulator steel pressure regulator is Single-stage diaphragms, vacuum structure Stainless diaphragms output. It has piston pressure reducing structure, constant outlet pressure, mainly used for high input pressure, suitable for purified gas, standard gas, corrosive etc.
Technical Data
1)Max inlet pressure: 500, 3000 psi
2)Outlet pressure: 0~25, 0~50, 0~100, 0~250, 0~500 psi
3)Proof pressure: 1.5 times of maximum rated pressure
4)Working temperature: -40°F-+165°F(-40°C-+74°C)
5)Leakage rate: 2*10-8 atm cc/sec He
6)Cv: 0.08
 | Typical applications
1)Laboratory
2)Gas Chromatograph
3)Gas Laser
4)Gas bus
5)Oil and chemical industry
6)Tested instrumentation |
